Kingwell Clear Ice Machines of Different Capacities

  • Product details image
Kingwell Clear Ice Machines of Different Capacities
Daily capacity: 500kg to 10ton per day Power form: 220/380V,60hz,3p or 380/415V,50hz,3p Refrigerant:R22 or R404a Block ice weight: 5-50kg/customized Cooling way: water cooling



Crystal and Transparent Block ice

Kingwell clear block ice machine is the patented product of Kingwell, now it's very popular in different countries, which can help customer to bring higher profit, the daily capacity ranges from 500kg to 20 tons, we have different sizes of block ice for your option:

Block ice weight

Ice size (thickness*width*height, mm)

Freezing time (hours)

Frequency of ice making per day (times)

5kg

80*120*600

6

4

10kg

80*250*600

6

4

15kg

100*300*600

8

3

20kg

100*400*600

8

3

25kg

150*330*600

12

2

30kg

150*400*600

12

2

50kg

220*330*800

24

1


Our standard design of clear block ice is 50kg, size 220x330x800mm, this ice can be cutted into different smaller square ice from 2x2x2cm to 8x8x8cm ice, or shape into sphere ice.
We can customize the block ice size according to customer's request.

Crystal and transparent block ice


The kind of block ice is crystal and transparent, it’s clean enough for drinking, most ofour clients are used for human consumption and ice sculpture.


Features of the clear ice macihne

  • Crystal, transparent, food-grade block ice: this kind of block ice is totally sanitary for human consumption, it meets the food-grade standard.

  • Block ice can be changeable: 5-100kg per piece, you can choose what you like, we can also design according to customers’ special requirements.

  • Anti-rust and Anti-corrosion material: We use Aluminum plate to make ice cans, it is a good material anti-rust and anti-corrosive, the ice is clean and beautiful, meanwhile the lifespan can be longer.

  • Power consumption: about 80-100KW*H to make 1 ton ice, it depends on the ambient temperature.

Water consumption: about 1.1tons water to make 1 ton ice.



Specifications

Item

Capacity

(tons/day)

Refrigerant

Compressor

Brand

Compressor

Power
(HP)

Weight of ice

(kg)

Cooling
Way

Dimension
(L*W*H, mm)

KW-TDB 1

1

R22/R404A

Bitzer

6

5/10

Water/Air

2400*1000*1800

KW-TDB 1.5

1

R22/R404A

Bitzer

6

5/10

Water/Air

2600*1100*1800

KW-TDB 2

2

R22/R404A

Bitzer

12

10

Water/Air

2800*1200*1950

KW-TDB 3

3

R22/R404A

Bitzer

18

10/25

Water/Air

3976*1468*2095

KW-TDB 5

5

R22/R404A

Bitzer

30

10/25

Water

4660*1712*2180

KW-TDB10
10 R22/R404A
Bitzer 80 50 water 11800*2220*2440

》 Power Supply:380~415V, 50Hz,3 phase;

220~240V, 60Hz, 3phases;

440~480V, 60Hz, 3phases;

380V, 60Hz, 3 phases.

》 Working Conditions: Input Water Temp: 21℃;

Ambient Temp: 25℃;

Condensing Temp: 40℃;

The actual capacity will be changed by different ambient temperature and make-up water temperature, actually it willreach at least 80%, at most 130%.

》 Guangzhou Kingwell reserves the right to change specifications and design without notice.
